Misting Systems
Smart High-Pressure Misting System
Landscape fog, cooling, humidification and air purification in one system
View detailsA compact high-pressure misting package sized for private courtyards, roof terraces, small gardens and café patios. The unit can be wall-mounted or placed out of sight, with tubing run along the fence or planting bed.
Despite the small cabinet, it uses the same high-pressure pump technology as our full-size systems: fine mist, low noise and a dry-mist feel that does not soak furniture or guests.
Specifications
| Working pressure | 70–100 bar |
|---|---|
| Droplet size | 1–15 μm |
| Unit power | 1.5–7.5 kW |
| Coverage area | 500–10,000 m² (depending on pump power and nozzle count) |
| Nozzle orifice | 0.15/0.2/0.3 mm |
| Water consumption | 3–8 L/min (with power) |
| Control mode | timer / sensor-linked / remote app |
| Noise level | ≤ 65 dB (quiet-running unit) |
| Protection | dry-run, over-pressure and filter-blockage protection |
| Service life | pump unit ≥ 5 years, nozzles ≥ 2 years (periodic replacement recommended) |
Specifications are for the standard configuration. Final figures are confirmed in your quotation — tell us the application and we will size it for your site.
Key points
- Small footprint — Cabinet design for courtyards where a plant room is not available.
- Fine, dry mist — High-pressure atomisation produces fast-evaporating droplets instead of wet spray.
- Simple controls — Timer and manual control as standard; remote and sensor options available.
- Quiet operation — Low-noise pump unit so the system does not disturb outdoor conversation.
